LA1602Y 2B 200mm Clutch for Bock Bitzer AC Compressor

Model: LA1602Y
Rated Voltage : 24V
Max speed: 3800 rpm
Consumed Power: 60W
Groove type: 2B
We're here to help: Easy ways to get the answers you need.
DESCRIPTION

Brief Introduction of la1602y clutch


La1602y is magnetic clutch for bus ac compressor with Coil, 24V, LA16.02Y, 2B for Bock and Bitzer ac compressor.


OEM Code of la1602y linning clutch


00150156 -
030216900 - 13330B
- 300401029 -
30040402900 -
42536570 -
5006217562 - 50931
- 81066306066 -

Autoclima OEM code: 404561602
Application: LA16.02 2G "B"  193

Eberspächer - Sütrak (Carrier)

30,04,01,029
30 04 01 029
300401029

30,04,04,029-00
30 04 04 029-00
300404029-00
30040402900

88-67-01-00013-00
88670100013-00
8867010001300
00150156

Konvekta
H13-001-575-L
H13001575L
H13-001-575-L-01
H13001575L01
H13001575L01

Webasto-Spheros
13330B

Man
(Neoplan-Neoman)
8106630-6066
81.06630-6066

81066306066

IVECO
5006217562

Linnig
LA16.2Y
LA162Y

(Kendrion Markdorf)
LA16.02Y
LA1602Y


PARAMETERS

Technical of la1602y linning clutch


Model LA1602Y
Brand Linnig
Static Friction Torque 240Nm
Strap Wheel Slot/Groove Model 2B
Rated Voltage 24V
Consumption Power 60W
Max Speed 3800 rpm
